Products > Gasoline Engine > > Factory Price! 6.5HP 7HP 9HP 13HP 15HP Gasoline Engines with Different Shaft
Factory Price! 6.5HP 7HP 9HP 13HP 15HP Gasoline Engines with Different Shaft Factory Price! 6.5HP 7HP 9HP 13HP 15HP Gasoline Engines with Different Shaft Factory Price! 6.5HP 7HP 9HP 13HP 15HP Gasoline Engines with Different Shaft Factory Price! 6.5HP 7HP 9HP 13HP 15HP Gasoline Engines with Different Shaft
Product name : Factory Price! 6.5HP 7HP 9HP 13HP 15HP Gasoline Engines with Different Shaft
Product No. : FD170
Model Number : FD170
Engine Type : Air-Cooled, 4-Stroke, Ohv, Single Cylinder, Gasoline Engine
Starting System : Recoil Start
Trade Mark : Fusinda
Loading Port : Chongqing, China
Origin : Chongqing, China
H.S Code : 84079090
Package : Carton
             [Next Product]→
Online Inquiry         Email Us

  Details:
Basic Info
  • Model NO.: FD170
  • Speed: Speed
  • Intake Pressure Impulse: Naturally Aspirated
  • Fuel: Gasoline Engine
  • Cylinder Arrangement Form: L
  • The Valve Solved Carbon Deposition: Effectively Prolong The Lifespan of Engine
  • Easy Start, Easy Maintenance: Effectively Reduce The Heating and Noise
  • Ohv Design, Lower Temperature: More Power Output, More Endurable
  • Low Oil Shut Down System: Low Oil Alert System to Protect Engine
  • Transport Package: Standard Carton Box; Color Box Optional
  • Origin: Chongqing, China
  • Ignition Mode: Electric Ignition
  • Cooling Cylinder: Air-Cooled
  • Piston Movement: Reciprocating
  • Number of Strokes: Four-Stroke
  • Number of Cylinders: Single-Cylinder Machine
  • Integrated Type of Wind Scooper: Compact New Structure, Light Weight
  • Completely New Design of Crankcase: Lower Spray Volume of Oil, Less Fuel Consumption
  • Cast Iron Sleeve: Improved The Performance of Lubrication
  • Trademark: FUSINDA
  • Specification: CE
  • HS Code: 84079090
Product Description
Factory price! 6.5Hp 7Hp 9Hp 13Hp 15Hp gasoline engines with different shaft
Fusinda brand, Air Cooled, FD170F, single cylinder gasoline engine

Features:
* Advance OHV, air cooled, 4 stroke engine, delivers non-flunctuating power for longer time
* Light and compact design
* Low fuel consumption
* Easy and fast starting and installing
* Lower noise and small vibration
* The valve designed for carbon deposition prevention, which can effectively prolong the lifespan of engine
* Integrated type of wind scooper, effectively reduce the heating, better prolong the engine's lifespan
* Optimum inner structural design of cylinder head valve, effectively lower spray volume of oil, less fuel consumption
* OHV design, lower temperature with running engine, more power output, more endurable, can save more fuel
* Cast Iron Sleeve, effective improved the performance of lubrication, as well as make the engine to better stand wear and tear, to prolong the engine's lifespan
* Low oil shut down system, prevent engine to run in low oil condition, better protect engine


Specifications
1: High efficiency and low noise, low fuel consumption
2. Strong and stable power output, THD<5%
2: Compact design, Strong structure, more endurable
3: Easy maintenance and longer working life
4: Super Competitive price, most reliable partner

Engine Model: FD168F
(6.5HP)
FD168FB (6.5HP) FD170F
 (7HP)
FD188F (13HP) FD188F (13HP) FD190F (14HP) FD192F (16HP)
Rated power(Kw) 1.85 3.8 4.0 7.6 7.6 8.2 9.3
Displacements (cc) 196 196 208 389 389 420 459
Starting system Recoil start Recoil start Recoil start Recoil start Recoil start Recoil start Recoil start
Fuel Tank Capacity/L: 6 15 15 15 15 15 15
Oil capacity/L 0.45 0.6 0.6 0.6 0.6 0.6 0.6
Dimensions(LxWxH)/mm 470*385*430 605*445*500 605*445*500 605*445*500 700*530*595 700*530*595 700*530*595
Net Weight/Gross Weight 25/27 41/43 44/46 45/47 84/86 86/90 92/94
Quantity Per Container (set) 20': 360 20': 192 20': 192 20': 192 20': 136 20': 136 20': 136
 Quantity Per Container (set) 40': 900 40': 485 40': 485 40': 485 40': 292 40': 292
40':292
